Aqua Hot 100DE Heating System
£3,250.99
inc. VAT
Out of stock — contact us for lead time
Supplied through our authorised trade partner. Prices shown include VAT.
Unsure this part fits your van? Ask us first.
Description
- THE AQUA-HOT 100D SERIES IS A 2-IN-1 HYDRONIC HEATING SYSTEM THAT CAN PROVIDE HEAT
- AND TANK-LESS HOT WATER ON DEMAND USING AN EXTERNAL DIESEL BURNER AND A BUILT-IN ELECTRIC HEATING ELEMENT.
- DOWNLOAD 100DE INSTALL MANUAL
- 100DE SELL SHEET
- 100DE SPEC AND OPTIONS
- THE SYSTEM HEATS A GLYCOL SOLUTION THAT IS STORED IN THE AQUA-HOT BOILER TANK.
- THIS FLUID SOLUTION MUST BE UP TO OPERATING TEMPERATURE (ABOUT 80C) BEFORE THE AQUA-HOT
- WILL PROVIDE INTERIOR HEAT OR HOT WATER; IT MAY TAKE UP TO 10-15 MINUTES AFTER THE SWITCHING ON
- OF THE DIESEL BURNER AND/OR THE ELECTRIC HEATING ELEMENT.
- COMPACT COZY HEAT EXCHANGERS (SOLD SEPARATELY) CAN BE STRATEGICALLY PLACED TO DELIVER HEAT TO UP TO 3 DIFFERENT ZONES THROUGHOUT THE VAN.
- FUELED BY DIESEL AND OPERATED BY 12 V FOR OFF GRID APPLICATIONS.
- AVAILABLE WITH A 220 V ELECTRIC ELEMENT.
- THE ALL-IN-ONE DESIGN OF THE AQUA-HOT RESULTS IN CONSIDERABLE COST AND SPACE SAVINGS.
- HIGH ALTITUDE READY: GREAT PERFORMANCES UP TO 2.000 M.
- USER FRIENDLY: HEAT CONTROLLED BY YOUR LCD TOUCH CONTROL AND ENDLESS HOT WATER BY SIMPLY TURNING ON A FAUCET.
- RV-C OPEN SOURCE: EASY TO INTEGRATE IN THE RV?S CONTROL PANEL.
- MAXIMUM INTERIOR HEAT 22,000 BTU/HR (6,5 KW).
- Continuous, Tank-less Hot Water of 38- 40C at 3,5 l/min.
- Can control up to 3 different Climate Zones inside the vehicle.
- Electric Element (1,5 kW).
- Size (29,2 H x 19,0 W x 44,8 L) cm.
- Weight 20,4 Kg (empty) 26,7 Kg (full).
- Average Current Draw 5A, initial pick 7/8A.
- Fuel Consumption: 0,31 to 0,49 l/h.
